Year: 2019

Manufacturer: Grand Design RV

Model: Imagine 2800BH

RV Type: Travel Trailer / Bunkhouse Travel Trailer

Floorplan: 2800BH Bunkhouse with Front Bedroom, Outdoor Kitchen & Dual Entry

Overall Length: 32' 0"

Overall Height: 11' 1"

Overall Width: 8' 0"

Dry Weight: 6,195 lbs.

Hitch Weight: 605 lbs.

Sleeping Capacity: Up to 10

Slide-Outs: 1

Axles: 2

Hitch Type: Bumper Pull

Fresh Water Capacity: 52 gallons

Gray Water Capacity: 76 gallons

Black Water Capacity: 39 gallons

Air Conditioning: 15,000 BTU ducted main A/C

Furnace: 35,000 BTU high-capacity furnace

Water Heater: 17.8 gal./hr. quick-recovery water heater

LP Capacity: Two 20-lb. LP bottles

Electrical Service: 30-amp

Awning: Electric awning with LED lighting

Leveling: Power tongue jack

Exterior Storage: Drop-frame pass-through storage

Exterior Construction: Gel-coated fiberglass exterior with laminated aluminum-framed construction

Roof: One-piece roof membrane with 12-year warranty

Walls: Laminated aluminum-framed side and rear walls with R-7 insulation

Main Floor: Laminated aluminum-framed main floor with R-30 insulation

Roof Insulation: 5" radius wood-framed roof with R-40 insulation

Underbelly: Heated and enclosed underbelly with suspended tanks

Dump Valves: Heated and enclosed dump valves

Holding Tanks: Enclosed and heated

Fresh Water System: High-capacity water pump with oversized fresh-water drain

Black Tank: Black tank flush system

Solar: Solar power inlet

Battery: Battery kill switch located in pass-through storage

Exterior Windows: 80% tint radius safety-glass windows
