CHASSIS FEATURES

Spartan K4 Chassis

Cummins X15 605 HP Engine, Peak HP 605 @ 1,800 RPM

Allison 6 Speed Transmission MH 4000, Peak Torque 1,950 ft/lbs. @1,200 RPM

HWH Four Point Hydraulic Leveling Jack System

ABS Anti‐Lock Braking System with Automatic Slack Adjusters

270‐amp: Leece‐Neville Alternator

Automatic Traction Control (ATC)

Electric Engine Block Heater

Front Axle ‐ IFS

Performance Choice™ ‐ Anti‐Sway Bar with Selectable Drive Modes

Rear Axle Ratio: 4.30:1

Passive Steer Tag Axle with 17 Degree Turn Radius

20,000‐lb. Towing Capacity/ 2,000‐lb. Hitch Tongue with 7/4‐Pin Plug

Michelin Front 365/ 70R 22.5” Rear 315/ 80R 22.5”

3 Year Spartan Scheduled Maintenance Included

Complimentary Spartan Care Kit

EXTERIOR FEATURES

Foretravel Exclusive Fore‐Slide™ Flangeless Pneumatic Seals on All Slide Rooms

Outdoor Entertainment Package

380‐Watt Solar Panel Package

Storage Bay: Freezer on Slide Out Tray

Fresh Water Plumbing Supply Manifold

Paint Protection Below Windshield ‐ Armor Coat

Full Body Exterior Paint with Multiple Clear Coat Finishes

Utility Station

DASH and COCKPIT FEATURES

Passive Keyless Start (PKS)

15” Digital Valid Dash w/ VDC Control

Cameras: 8 Total, 2 Side Mounted Integrated in Mirrors, 6 Perimeter 360 Delta Mobile Camera System

APPLIANCES • ELECTRONICS

LED Smart TVs

LED Smart TV Outside in Patio Entertainment Package

Silverleaf Total Coach Control System

Wi‐Fi Ranger, Converge Model

Winegard‐Rayzar Automatic Domed HDTV Antenna

StarLink

Residential Refrigerator

HEATING • COOLING • ELECTRICAL

Onan 12.5 Kw Diesel Generator in Quiet Box

Aqua‐Hot Hydronic Heating 450D (Floorplan Dependent)

12‐Volt Battery Disconnect

Dual 3000‐Watt Xantrex Inverter/Charger

50‐Amp Shoreline Connection

Air‐Conditioning, Ducted with 3 Roof Airs 15,000 BTU’s with Heat Pumps

Floor Tile Heating System

SAFETY FEATURES

All Coaches Built to RVIA Specifications

Spartan Advanced Protection System: Collision Mitigation with Adaptive Cruise Control and Active Braking, Electronic Stability Control Automatically Brakes Individual Coach Wheels to Help Drivers Maintain Control During Extreme Steering Maneuvers.

Automatic Traction Control (ATC)

CAPACITIES AND MEASUREMENTS

Fresh Water 120 Gallons

Waste Water Tank 160 Gallons

Fuel Tank 200 Gallons

DEF Tank 15 Gallons

Interior Height 84”

Exterior Height 13’2” ‐ Top of Roof A/C’s

Wheelbase 316”
