CHASSIS FEATURES

Foretravel Travelride III Chassis - by Spartan

 All Air Ride with:
     Two Air Bags (IFS front axle)

     Four Outboard-Mounted Air Bags (Drive Axle)

     Two Air Bags (Tag Axle)

Cummins X15 605 HP Engine

Spartan Cummins Connect

Spartan Safe Haul

Engine Brake: Three Stage Engine Brake with On/ Off Switch

ABS Anti-Lock Braking System with Automatic Slack Adjusters

Air Disc Brakes on all Wheels

Air Hose for Tire Service

Air line with Quick Connect

Alcoa Aluminum Wheels with Dura-Bright Protection

Allison 6 Speed Transmission MH 4000

Alternator - 350-amp: Leece-Neville

Automatic Traction Control (ATC)

Auxiliary 12V Air Compressor

Fuel Filter / Water Separator

Front Axle - IFS (Independent Front Suspension)

HWH - Active Air System and Computerized Air Leveling System

Ridewell Independent Tag Axle

Rear Axle Ratio: 4.30:1

20,000-lb. Towing Capacity/ 2,000-lb. Hitch Tongue with 7/4-Pin Plug

Michelin Tires:  Front 365/ 70R 22.5”   Rear 315/ 80R 22.5”

HEATING • COOLING • ELECTRICAL

Onan 12.5 Kw Diesel Generator in Quiet Box

12-Volt Battery Disconnect

Dual 2800 Watt Inverter/ Charger with Integrated AC/DC Surge Protectors

50-Amp Shoreline Connection

Air-Conditioning and Heating with Offset Returns for Superior Quiet Operation

Air-Conditioning, Ducted with 4 Roof Airs (45) 15,000 BTU’s with Heat Pumps

Auto Temp. Start for Generator

Low-Battery Auto-Start for Generator

Six 4D House Batteries/ Two Engine Batteries, Group 31 with 950 CCA- Each

50-Amp Automatic Transfer Switch with Integrated Surge Suppression2010

Electrical Surge-Suppression System

Aqua Hot Hydronic Heating 600D

CAPACITIES AND MEASUREMENTS

Fresh Water: 135 Gallons

Holding Tank: 145 Gallons

Fuel: 200 Gallons

DEF: 15 Gallons

Interior Height: 84” / 87” in Recesses

Exterior Height: 13’2” - Top of Roof A/C’s

CHASSIS RATINGS

GVWR:  54,000 lb.

Front GAWR: 20,000 lb.

Rear GAWR: 20,000 lb.

Tag GAWR: 14,000 lb.

GCWR: 74,000 lb.
