The 2014 Thor Motor Coach A.C.E. 29.2 is a Class A motorhome designed with quality and comfort in mind. With a mileage of 51,840, this vehicle has been well-traveled and is ready for new adventures.

Engine & Powertrain
- **Engine Type:** Triton V10 gasoline engine
- **Displacement:** 6.8 liters
- **Horsepower:** Approximately 362hp @ 4,750RPM
- **Torque:** Approximately 457ft-lbs @ 3,250RPM
- **Transmission:** 5-speed automatic (TorqShift with overdrive)
- **Chassis:** Built on a Ford F-Series Super Dutystyle chassis
- **Driveline Configuration:** 4×2
- Oil used is AMSOIL Fully Synthetic

Dimensions & Chassis Specifications (29.2 Specific)
- **Exterior Length:** Approximately 297
- **Wheelbase:** Approximately 190 inches
- **Gross Vehicle Weight Rating (GVWR):** 16,000 lbs
- Steering - Added Matched Steering Stabilizer. Makes driving as easy as a 3/4
ton truck.
- Suspension - Front and Rear SUMO SPRINGS added.

Capacities & Fluid Tanks
- **Fuel Tank Capacity:** 80 gallons
- **Water Storage:**
- **Fresh Water:** 50 gallons
- **Gray Water:** Approximately 44 gallons
- **Black Water:** Approximately 29 gallons
- **Propane Storage:**
- **Tank Capacity:** Around 20.8 gallons
- **Total Propane:** Up to 88 lbs

This particular model is equipped with all the amenities needed for a comfortable road trip, including a cozy sleeping area, a functional kitchen, and a bathroom. The A.C.E. 29.2 is the perfect combination of luxury and practicality, making it an ideal choice for both short weekend getaways and long cross-country trips.

Interior Systems & Layout
- **Kitchen Area:**
- Center-positioned with a pedestal-style table
- Equipped with a 3-burner oven/stove and a mid-size refrigerator (dual mode: electric/propane)
- **Living Area & Sleeping Arrangements:**
- Convertible sofa, often counts as an additional sleeping surface 1 or 2 persons
- Over driving area bed - folds up and down. 1 or 2 persons
- Overall sleeping capacity accommodates up to 6 occupants with a mix of
fixed and convertible option
- Added small Deep freezer beside master bed for long trips.

- **Bathroom:**
- Single bathroom featuring vinyl flooring, porcelain fixtures, a centrally located sink, and a shower area
- **Master Bedroom:**
- Includes carpet flooring, built-in closet with mirror, and window treatments (e.g., shades or curtains)

Climate, Comfort & Utility Systems
- **Furnace:** 34,000 BTU for heating
-**Front Central Duct A/C** on main Thermostat.
-** Add Aftermarket - Atwood Air Command A/C unit in place of rear Vent
Fan. - 20 Plug-in on exterior near main 30 amp plugin.
- **Water Heater:** 6-gallon capacity unit
- **Ventilation:
- Front Vent Overhead fans in the living areas to promote air circulation
- Coach Batteries - has 2 RENOLGY 100 amp/10 hr sealed lead acid batteries.

The exterior of the vehicle is sleek and modern, with a design that is sure to turn heads on the road. The Class A classification means that this motorhome is larger and more spacious than other RV classes, providing ample room for passengers to relax and enjoy the journey.

Exterior Features & Storage
- **Slideout:**
- Power retractable slideout on Drivers side.
- **Awning:**
- One power retractable awning, roughly 14 ft in length
- **Exterior Storage:**
- Storage capacity ranges about 80 cubic feet


Construction, Materials & Build Systems
- Exterior Build:**
- Aluminum sidewalls and fiberglass doors
- **Roof Assembly:**
- Typically features a one-piece exterior TPO membrane
- Equipped with block foam insulation in the roof, wall, and floor assemblies
- Layers are vacuum bond laminated for even glue coverage
- **Interior Flooring Options:**
- Residential vinyl or carpet flooring
- **Structural Support:**
- Uses OSB wood bases combined with structural steel framing

- Also have Blue Ox 10k vehicle towbar.
- EVEN BRAKE remote brake box system.

- No roof leaks - stored in shed most of its life.
- Axxera system with Rear back up camera and right and left side signal
cameras built into mirrors.
- LCI electronic auto leveling system (hydraulic)


Overall, the 2014 Thor Motor Coach A.C.E. 29.2 is a reliable and well-maintained vehicle that is ready to hit the road. Whether you are a seasoned RV'er or a first-time buyer, this motorhome offers everything you need for a memorable and comfortable travel experience. With its spacious interior and quality construction, the A.C.E. 29.2 is sure to provide many years of adventure and enjoyment for new owner.
